Performance

AC Input:

230V / 6,3A

Frequency:

50 Hz

+5V:

22A

+3,3V:

22A

+5V & +3,3V combined:

130W

+12V 1:

52,5A/630W

+12V 2:

N/A

+12V 1 & +12V 2 combined:

N/A

+12V 3:

N/A

+12V 4:

N/A

+12V 3 & +12V 4 combined:

N/A

P.F.:

>0,9

-12V:

0,3A / 3,6W

+5VSB:

2,5A / 12,5W

Maximum Load:

700W

Connectors

Native cable:

24PIN:

===450mm===[24PIN]

SATA/Molex:

===350mm===[SATA]===150mm===[SATA]===150mm===[SATA]===150mm===[Molex]

SATA/Molex:

===350mm===[SATA]===150mm===[SATA]===150mm===[SATA]===150mm===[Molex]

6+2 PCIe:

===450mm===[PCIe]===150mm===[PCIe]

8PIN EPS (4+4):

===500mm===[4PIN EPS]===150mm===[4PIN EPS]
