Hi-Speed USB 2.0 Active Cable
USB A Male to B Male, 15 m (50 ft.), Black

• Extends and boosts the signal to any USB device – supports data transfer speeds up to 480 Mbps
• Built-in chipset with amplification maintains Hi-Speed, USB 2.0 signal quality, electrical and timing specifications
• Overcomes the 5 m (16 ft.) USB distance limitation – ideal for connecting most USB printers

Easily overcome distance limitations to connect USB devices. Use the Manhattan Hi-Speed USB Active Cable to connect a computer USB port to a USB printer or other USB Type-B male device almost anywhere in the room. This single, non-daisy-chainable cable extension provides a convenient, uninterrupted 15 m (50 ft.) connection. The Manhattan Hi-Speed USB Active Cable with built-it repeater is fully-compliant with USB 1.1 and Hi-Speed USB 2.0 specifications to help devices operate at maximum performance. No external power or driver requirements are necessary. Plug-and-play capable and Windows/Macintosh versatility provide greater options in computer and peripheral placement and office layout.

Features:

• Extends and boosts the signal to any USB device – supports data transfer speeds up to 480 Mbps
• Built-in chipset with amplification maintains Hi-Speed, USB 2.0 signal quality, electrical and timing specifications
• Overcomes the 5 m (16 ft.) USB distance limitation – ideal for connecting most USB printers
• Provides a single, non-daisy-chainable extension for maximum distance of 15 m (50 ft.)
• Plug and Play; Windows and Mac compatible – bus-powered requires no external power supply
• Three-Year Warranty

Specifications:

Standards and Certifications
CE
FCC
USB 2.0
RoHS

General
Throughput: 480 Mbps
Bus powered
Maximum non-daisy-chainable length: 15 m (50 ft.)
Power: 5 VDC / 1 A

Connections
One Type-A male
One Type-B male

Physical
LED indicators: power and port connection
Housing: plastic
Length: 15 m (50 ft.)
Weight: 0.38 kg (12.2 oz.)

Operating enviroment
Operation temperature: 0 – 40°C (32 – 104°F)
Storage temperature: -20 – 60°C (-4 – 140°F)
Humidity (noncondensing): 0 – 96%

Package Contents
Hi-Speed USB 2.0 Active Cable
Quick Instruction Guide
